Web/Spring
MyBatis-Spring
당진개발자
2024. 4. 22. 14:25
1. MyBatis
2. MyBatis-Spring
3. 코드 예제
1) pom.xml에 라이브러리 추가
<!-- MySql & MyBatis -->
<!-- https://mvnrepository.com/artifact/com.mysql/mysql-connector-j -->
<dependency>
<groupId>com.mysql</groupId>
<artifactId>mysql-connector-j</artifactId>
<version>${com.mysql-version}</version>
</dependency>
<!-- https://mvnrepository.com/artifact/org.mybatis/mybatis -->
<dependency>
<groupId>org.mybatis</groupId>
<artifactId>mybatis</artifactId>
<version>${org.mybatis-version}</version>
</dependency>
<!-- https://mvnrepository.com/artifact/org.mybatis/mybatis-spring -->
<dependency>
<groupId>org.mybatis</groupId>
<artifactId>mybatis-spring</artifactId>
<version>${org.mybatis-spring-version}</version>
</dependency>
2) root-context.xml 작성
- dataSource : DB Connection Pool 설정, context.xml에 설정 파일 존재
- sqlSessionFactoryBean : sqlSessionFactoryBean 설정, alias 설정, mapper 경로 설정
<?xml version="1.0" encoding="UTF-8"?>
<beans xmlns="http://www.springframework.org/schema/beans"
xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
xmlns:context="http://www.springframework.org/schema/context"
xmlns:aop="http://www.springframework.org/schema/aop"
xmlns:tx="http://www.springframework.org/schema/tx"
xmlns:mybatis-spring="http://mybatis.org/schema/mybatis-spring"
xsi:schemaLocation="http://mybatis.org/schema/mybatis-spring http://mybatis.org/schema/mybatis-spring-1.2.xsd
http://www.springframework.org/schema/beans https://www.springframework.org/schema/beans/spring-beans.xsd
http://www.springframework.org/schema/context http://www.springframework.org/schema/context/spring-context-4.3.xsd
http://www.springframework.org/schema/aop http://www.springframework.org/schema/aop/spring-aop-4.3.xsd
http://www.springframework.org/schema/tx http://www.springframework.org/schema/tx/spring-tx-4.3.xsd">
<!-- Root Context: defines shared resources visible to all other web components -->
<context:component-scan base-package="com.ssafy.*.model,com.ssafy.util,com.ssafy.board.aop"/>
<aop:aspectj-autoproxy/>
<!-- <bean id="ds" class="org.springframework.jdbc.datasource.SimpleDriverDataSource">
<property name="driverClass" value="com.mysql.cj.jdbc.Driver"/>
<property name="url"
value="jdbc:mysql://127.0.0.1:3306/ssafyweb?serverTimezone=UTC&useUniCode=yes&characterEncoding=UTF-8"/>
<property name="username" value="ssafy"/>
<property name="password" value="ssafy"/>
</bean> -->
<bean id="dataSource" class="org.springframework.jndi.JndiObjectFactoryBean">
<property name="jndiName" value="java:comp/env/jdbc/ssafy"></property>
</bean>
<!-- <bean id="sqlSessionFactoryBean" class="org.mybatis.spring.SqlSessionFactoryBean">
<property name="dataSource" ref="dataSource"/>
<property name="configLocation" value="classpath:mybatis-config.xml"/>
<property name="mapperLocations">
<list>
<value>classpath:mapper/member.xml</value>
<value>classpath:mapper/board.xml</value>
</list>
</property>
</bean> -->
<bean id="sqlSessionFactoryBean" class="org.mybatis.spring.SqlSessionFactoryBean">
<property name="dataSource" ref="dataSource"/>
<property name="typeAliasesPackage" value="com.ssafy.*.model"/>
<property name="mapperLocations" value="classpath:mapper/*.xml"/>
</bean>
<!-- <bean id="sqlSession" class="org.mybatis.spring.SqlSessionTemplate">
<constructor-arg ref="sqlSessionFactoryBean"></constructor-arg>
</bean> -->
<!-- <bean id="boardMapper" class="org.mybatis.spring.mapper.MapperFactoryBean">
<property name="mapperInterface" value="com.ssafy.board.model.mapper.BoardMapper"/>
<property name="sqlSessionFactory" ref="sqlSessionFactoryBean"/>
</bean> -->
<!-- mybatis에서 제공하는 scan 태그를 통해 repository(Mapper) interface들의 위치를 지정. -->
<mybatis-spring:scan base-package="com.ssafy.*.model.mapper"/>
<!-- 트랜잭션 관리자 설정 -->
<bean id="transactionManager" class="org.springframework.jdbc.datasource.DataSourceTransactionManager">
<property name="dataSource" ref="dataSource" />
</bean>
<!-- 어노테이션 기반 트랜잭션 설정 -->
<tx:annotation-driven transaction-manager="transactionManager"/>
</beans>
3) BoardMapper.java
package com.ssafy.board.model.mapper;
import java.sql.SQLException;
import java.util.List;
import java.util.Map;
import org.apache.ibatis.annotations.Mapper;
import com.ssafy.board.model.BoardDto;
import com.ssafy.board.model.FileInfoDto;
@Mapper
public interface BoardMapper {
void writeArticle(BoardDto boardDto) throws SQLException;
void registerFile(BoardDto boardDto) throws Exception;
List<BoardDto> listArticle(Map<String, Object> param) throws SQLException;
int getTotalArticleCount(Map<String, Object> param) throws SQLException;
BoardDto getArticle(int articleNo) throws SQLException;
void updateHit(int articleNo) throws SQLException;
void modifyArticle(BoardDto boardDto) throws SQLException;
void deleteFile(int articleNo) throws Exception;
void deleteArticle(int articleNo) throws SQLException;
List<FileInfoDto> fileInfoList(int articleNo) throws Exception;
}
4) board.xml
- namespace는 mapper 인터페이스의 full name을 작성
- sql id는 인터페이스의 메서드 명으로 작성
<?xml version="1.0" encoding="UTF-8" ?>
<!DOCTYPE mapper PUBLIC "-//mybatis.org//DTD Mapper 3.0//EN"
"http://mybatis.org/dtd/mybatis-3-mapper.dtd">
<mapper namespace="com.ssafy.board.model.mapper.BoardMapper">
<resultMap type="boardDto" id="article">
<result column="article_no" property="articleNo"/>
<result column="user_id" property="userId"/>
<result column="user_name" property="userName"/>
<result column="subject" property="subject"/>
<result column="content" property="content"/>
<result column="hit" property="hit"/>
<result column="register_time" property="registerTime"/>
</resultMap>
<resultMap type="boardDto" id="viewArticle" extends="article">
<collection property="fileInfos" column="article_no" javaType="list" ofType="fileInfoDto" select="fileInfoList"/>
</resultMap>
<resultMap type="fileInfoDto" id="file">
<result column="save_folder" property="saveFolder"/>
<result column="original_file" property="originalFile"/>
<result column="save_file" property="saveFile"/>
</resultMap>
<insert id="writeArticle" parameterType="boardDto">
insert into board (user_id, subject, content, hit, register_time)
values (#{userId}, #{subject}, #{content}, 0, now())
<selectKey resultType="int" keyProperty="articleNo" order="AFTER">
select last_insert_id()
</selectKey>
</insert>
<insert id="registerFile" parameterType="boardDto">
insert into file_info (article_no, save_folder, original_file, save_file)
values
<foreach collection="fileInfos" item="fileinfo" separator=" , ">
(#{articleNo}, #{fileinfo.saveFolder}, #{fileinfo.originalFile}, #{fileinfo.saveFile})
</foreach>
</insert>
<sql id="search">
<if test="word != null and word != ''">
<if test="key == 'subject'">
and subject like concat('%', #{word}, '%')
</if>
<if test="key != 'subject'">
and ${key} = #{word}
</if>
</if>
</sql>
<select id="listArticle" parameterType="map" resultMap="article">
select b.article_no, b.user_id, b.subject, b.content, b.hit, b.register_time, m.user_name
from board b, members m
where b.user_id = m.user_id
<include refid="search"></include>
order by b.article_no desc
limit #{start}, #{listsize}
</select>
<select id="getTotalArticleCount" parameterType="map" resultType="int">
select count(article_no)
from board
<where>
<include refid="search"></include>
</where>
</select>
<select id="getArticle" parameterType="int" resultMap="viewArticle">
select b.article_no, b.user_id, b.subject, b.content, b.hit, b.register_time, m.user_name
from board b, members m
where b.user_id = m.user_id
and b.article_no = #{articleNo}
</select>
<select id="fileInfoList" resultMap="file">
select save_folder, original_file, save_file
from file_info
where article_no = #{articleNo}
</select>
<update id="updateHit" parameterType="int">
update board
set hit = hit + 1
where article_no = #{articleNo}
</update>
<update id="modifyArticle" parameterType="boardDto">
update board
set subject = #{subject}, content = #{content}
where article_no = #{articleNo}
</update>
<delete id="deleteFile" parameterType="int">
delete from file_info
where article_no = #{articleNo}
</delete>
<delete id="deleteArticle" parameterType="int">
delete from board
where article_no = #{articleNo}
</delete>
</mapper>
